Fixtures are also called fixtures. In a broad sense, any process in the process, the device used to quickly, easily and safely install the workpiece can be called a fixture. Such as welding fixtures, inspection fixtures, assembly fixtures, machine tool fixtures, etc. Often referred to simply as a jig.
  The fixture is a process device used to quickly fasten the workpiece to maintain the correct relative position during processing. That is to say, the tooling fixture is an indispensable part of machining. Driven by the development of technology in the direction of high speed, high efficiency, precision, integration, intelligence and environmental protection, the fixture technology is moving towards high precision, high efficiency, modularity, combination, general purpose and economy. direction development.
When the fixture is processing the workpiece, in order to make the surface of the workpiece meet the technical requirements such as the size, geometric shape and mutual position accuracy with other surfaces specified in the drawing, the workpiece must be installed (positioned) and clamped (clamping) before processing.
  The fixture is usually composed of positioning elements (determining the correct position of the workpiece in the fixture), clamping device, and indexing device, so that the workpiece can complete the processing of several stations in one installation. There are rotary indexing devices and linear moving indexing devices. Two types, connecting elements and clamp bodies (clamp bases), etc.
When using the fixture, it is beneficial to ensure the machining accuracy of the workpiece and stabilize the product quality; it is beneficial to improve labor productivity and reduce costs; it is beneficial to improve the working conditions of workers and ensure safe production; .
  The use of fixtures is very high in manufacturers. In order to improve production efficiency and product quality in production, tooling fixtures are often used in the middle and later stages of production for functional testing or auxiliary assembly (which can assemble a fixed shape and height, etc.).
The actual use in the manufacturing plant is very wide, because it is non-standard customization, you can do it if you think of it.

  Company since its establishment, in line with "the pursuit of all staff of both material and spiritual happiness at the same time, for customers, contribute to the progress of human society development" management idea, from the early auto parts factory developed into a professional research and development, manufacture all kinds of automobile welding jig, test fixture, robot workstation,  Non-standard automation equipment and precision parts processing as one of the integrated manufacturing enterprises.
